Takeuchi announced in 2014 the launch of two updated versions of compact wheel loaders in series production at once.
The key features of the new products, which received the indexes TW65 Series 2 and TW80 Series 2, are the engine and hydraulics.
With the remaining very compact dimensions, both wheel loaders have much higher performance than their predecessors, which have proven themselves from this point of view, as well as possible.
The working height of the new products is 2.6 meters.
Takeuchi TW65 Series 2 lifting capacity with an operating weight of 5150 kg reaches 1830 kg, the breakout force at the bucket edge is 5200 kg.
Similar figures for the TW80 Series weighing 5760 kg are 2016 kg, 6300 kg, respectively.
Both are powered by a water-cooled, turbocharged Deutz diesel engine that meets the Tier IV Final eco-standard.
Its torque is 260 Nm at 1800 rpm and power is 73 hp. at 2200 rpm. Loaders are offered with two transmission options.
In the basic version, their maximum speed is 20 km / h, and with the optional gearbox and hydraulic accumulator to reduce the buildup - 39 km / h.
Another innovation is the modernized cab. Already in the basic version it is equipped with a heating and air conditioning system, as well as adjustable armrests for the operator's seat.
The glass door is distinguished by the absence of a steel frame, which significantly improved visibility.
In addition to it, a new multifunctional joystick has appeared in the cab, to which the auxiliary hydraulic pump is controlled.
It increases hydraulic performance up to 98 liters per minute.
